XLF-2400 Horizontal Automatic Continuously Foaming machine

XLF-2400 Horizontal Automatic Continuously Foaming machine

Product Description

XLF-2400 Horizontal Automatic Continuously Foaming Line

Product Presentation

This Machine is mostly used for producing soft urethane foam rubber productions (density is about 10-50kg/m3). Its automation level is high, the
Production is low-cost and operation is simple. It is desirable equipment to manufacture products of foam rubber in furniture, shoes, circumference, electron, clothing and automobile industry.

Main Technical Specification

Model XLF-2400
Oven length 17.5m
Foaming height <1.25m
Foaming width 1250~2350mm
Foaming density 10-15kg/m3
Total power 150kw
Linking conveyor belt length 17.5m
Side board adjustment width 0.98~2.3m
Conveyor belt speed 3500mm/min~6800mm/min
Mixing-head power 37kw
Total output 100~300kg/min
Machine external size L34000*W4550*H3200mm
